Polymer Eurocone adapter for multilayer PE-RT/Al/PE-RT pipes:
• around 30% cheaper than brass equivalent,
• 100% functional replacement for brass equivalent,
• the same assembly technique,
• the same operating parameters,
• Element available on stock.
Novelties on KAN-therm PP:
PP-R saddle fittings with Push connector
Tools set for saddle fittings montage:
Possibility of creation of individual heating systems acc. to investment specification:
KAN-therm Underfloor Heating:
New mixing unit with three-way mixing thermostatic valve:
•temperature pre-set range 20-43 °C
•optimal cooperation with low temperature heating sources
New, more condensed concrete additive BETOKAN (New Formula):
• increased efficiency and better performance,
• 2 to 4 times smaller doses compared to older BETOKAN,
• Dosage 0,25% – 0,6% of cement weight (average 200 ml / 50 kg cement),
• resistant to freezing – in case of freezing just defrost, shake and mix until reaching homogenous consistency,
• multi language labels (PL/RU/ENG)
• available after old version stock ends.
Underfloor heating – 73A & 77A series manifolds
Due to ErP directive, we change availability status of 73A & 77A series manifolds with standard 3 gear pumps for different markets:
• over UE markets elements will be available till 31.07.2015,
• outside UE markets elements will be available as before.
Due to ErP directive, new 73E & 77E series manifolds are equipped with energy efficient electronically modulated pumps (Wilo Yonos Para RKA 25/6).
Underfloor heating – stainless steel manifolds
Manifolds have following characteristics:
• beams from stainless steel, profile 1 1/4”,
• connection GW 1”,
• each beam has air vent and drain vent at the last circuit (10 –circuit manifold has the beam length the same as 11 -circuit manifold),
• each beam has plug on the right side of the manifold,
• each manifold has two galvanized steel clamps with inserts damping vibration,
• output for particular heating circuits in the form of male nipples ¾” with spacing of 50 mm,
• upper beam with valves for actuators with thread M30x1,5 mm,
• lower beam has flowmeters 0 – 2,5 l/min
•beams marked with arrows – NOTE: supply beam is LOWER beam!
System KAN-therm Tacker clips:
• Change of packaging of clips on tape, code 22022S from 25/875 to 50/1000,
• Change of packaging of short clips on tape, code K-200601 from 50/any to 50/1000,
• For all above mentioned Tacker clips catalogue price was changed – all prices are given for 1 piece.
